Whether a manual transmission or an automatic transmission is more useful in a car is always a question, a matter of debate. It is also a big deal to choose the right one when the transmission is used in the car. There are two types of transmission. And most formula cars use a manual transmission and why or why not. Why is it recommended to use manual transmission for high torque and sudden change of position?
A manual transmission is a combination of many components such as gears, shafts, etc. arranged in different designs, which provide the correct torque and speed ratios and which work for different types of roads. High torque to high speed and vice versa is done manually and the driver pushes the gear lever up or down to keep the balance right.
Cars that have a manual transmission usually have N speeds. Which are with or without reverse configuration. Here N means the number of speed ratios. For example, Maruti Suzuki Swift cars are 5-speed, 1-reverse.
Why do you need a manual transmission in the car?
Manual transmission or manual gearbox is an important part of a motor vehicle at all times. Since the introduction of this transmission, this manual transmission has been used in about 50-60 percent of the total vehicles. The reason for using the manual transmission in the car is the convenience of its use.
1. High torque is required due to the road conditions when the car is suddenly carrying the extra load for various reasons. The manual transmission is used for these tasks in the car as it provides a high torque ratio to the manual transmission.
2. When we rush a racing car or a curved truck to change gears from high torque to high speed and if this is always done then of course manual transmission is required in the car. This means that manual transmission plays a very important role in changing gears quickly.
3. Manual transmission or gearbox is essential for the operation of heavy vehicles or trucks on steep roads or hilly roads.
4. Because of the low cost and low maintenance of the vehicle, the manual transmission is used more in commercial vehicles.
What are the components of a manual transmission?
1) Shaft
Three types of shafts are commonly used in manual transmissions.
Main Shaft
Also known as the main shaft output shaft. It is placed in front of the clutch shaft in the same place as the le shaft. Gears, gear levers These are connected to the mesh-like device Doug Clutch-like device to the automotive gear shifting device which is mounted on top of this clutch.
Countershaft / le shaft
This shaft is used as a connector between the main shaft and the clutch shaft. It is usually connected below and parallel to the main shaft. And this le shaft acts as the engine output carrier to operate the clutch shaft from the main shaft.
Clutch shaft
The rotating output that comes from the engine flywheel is carried by these clutch transmissions which engage or release the output that is received from the engine.
2) Gear
There are 4 types of gears used in the manual gearbox.
Spar gear
This gear is usually used in old type fake gearboxes. This type of gear has straight dentures.
Helical gear
These are specially arranged modern and angular shaped teeth.
Bevel
These gears are the best of all gears. The angular incisors of these have scaly teeth.
Idler gear
This gear is very small and is usually used as reverse gear and is carried over the le shaft.
3) Meshing Device
Two types of mashing devices are commonly used in manual transmission.
Doug Clutches
Continuous gear machining is done in the gearbox through this device.
Synchromesh device
These devices are used for machining in synchromesh gearboxes. These devices simply work to change the shift of the car’s gears.
4) Gear liver
This lever is used by the driver for a gear shift.
Manual gearbox type:
1. Sliding Mesh gearbox
This type of gearbox is the oldest in terms of use. These are 3 shift manual spiders.
2. Constant Mesh Gearbox
This is the modern part of the gearbox used earlier. These are 4/5 shift manual and 1 reverse manual shift.
3. Synchromesh gearbox
This gearbox has been used for decades. These are 5 shift manual and 1 reverse manual shift.
So considering all the aspects, it can be said that manual transmission can be more convenient proof for a car. Manual transmissions are more popular and widely used to increase the durability of your vehicle or to increase the efficiency of heavy vehicles.
